Solar Panel Cables and Wires for PV Systems

4mm2 Solar Cable Interconnecting Solar Panel Arrays

4mm2 Solar Cable is International standard with TUV certification. Used in photovoltaic power generation. Solar Cables interconnect solar panels and other electrical components of a photovoltaic system. Sea Forest's Solar Cables and Wires are designed to be UV resistant and weather resistant.

Brand:
SEA FOREST
Item NO.:
4mm2
Order(MOQ):
100M
Payment:
T/T , L/C
Product Origin:
China
Color:
Black/Red
Shipping Port:
Shanghai/Xiamen
Lead Time：
7-15days

Inquiry now

Product Detail

4mm2 Solar Cable Interconnecting Solar Panel Arrays

Solar Cables Advantage：

1.Applied for solar system connection

2.UV-Proof, more than 25 years life

3.TUV and UL approval

Solar Wires Main features:

1.High thermolysis efficiency

2.High quality with anti-dust, anti-UV&anti-aging

3.High resistance against oil, steam, bacteria&ozone

4.Creative technique for conductivity

5.Temperature range for applications -40℃~+125℃

6.Short circuit resistance up to +280

7.Electron beam cross-linked materials do not melt or flow,even at high temperatures

8.High resistance again heat, clod,abrasion,UV,ozone and hydrolysis.

9.Very high mechanical robustness and resistance against water,oil and chemicals.

10.Flexible, easy to strip

11.Halongen free, High flame retardant

12.TUV Rheinland approval.

13.double insulated covering, electron heam, cross linked.

14.It can be used for off-grid and grid connected PV System.

PV Solar Cable CONSTRUCTION:

Conductor	Cross-sectional Area	4.0mm²
	Material	Copper
	Conductor Construction	56/0.3 n/m
	Stranded OD.	2.06mm

ELECTRICAL CHARACTERISTICS:

Rated Voltage	DC 1500V
Conductor Max.Resistanc e AT20℃(Ù)	5.09
Rated Current AT60℃(A)	55
Cable OD(mm)	6.05

PACKING:250m/500m/1000m, Roll, As Per Customer Request

Photovoltaic Cable and Wire IMAGE:

Solar cable and connector

Photovoltaic Cables

Solar panels cables

Leave A Message

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
